Name: Throw Ratio Short Throw Glass Projector Lenses Optical Double Concave
SKU: 175
Availability: InStock

Description
Reviews (0)

Throw Ratio Short Throw Glass Projector Lenses Optical Double Concave

Wide Angle Digital Projector Lens Compatible for most models in the market

E.g

CB-L1100U

CB-L1300U

CB-L1200U

CB-G7800

CB-G7200W

CB-G7100

CB-G7900U

CB-G7500U

CB-G7000W

CB-G7400U

etc
Each Lens has passed strickly testing before Leaving our workshop
All lenses would be tested to show good image performance. If any problem, please be free to forward us.
Good price, Good effect, No less than the original ones.
Our price is much more cheaper compared to the original ones. Our lens performance is no less than Original ones.
Enough Stock. Express door to door service.
We sold 6K-8K a year. We have enough stock for hot selling lens. If you have demand, we can send within the shortest time.
Each lens would be send by Express door to door service, only 5-7 days, you would get your ordered lens.

Model	Brightness	Resolution	Chip	Lens Model & Throw Ratio
Model	Brightness	Resolution	Chip	EL0808Y
CB-L1100U	6000	WUXGA	0.76’’	0.8:1
CB-L1300U	8000	WUXGA	0.76’’	0.8:1
CB-L1200U	7000	WUXGA	0.76’’	0.8:1

Model	brightness	Resolution	Chip	Throw Ratio
Model	brightness	Resolution	Chip	EL0808Y
CB-G7800	8000	XGA	0.79’’	0.8:1
CB-G7200W	7500	WXGA	0.76’’	0.8:1
CB-G7100	6500	XGA	0.79’’	0.8:1
CB-G7900U	7000	WUXGA	0.76’’	0.8:1

CB-G7500U	6500	WUXGA	0.76’’	0.8:1
CB-G7000W	6500	WXGA	0.76’’	0.8:1
CB-G7400U	5500	WUXGA	0.76’’	0.8:1

Model Name	LCD 0.8
Resolution (Typical)	0.76"WUXGA
Throw Ratio (T/R)	0.79
Type	Fixed Focus
Telecentric	Yes
F/#	F2.4
Offset Ratio	90%
Screen Size @ 1m	59"
Focus Length (f) mm	13.55
MTF(@67lp/mm)	>45%
Chromatic Aberration	≦0.8pix
Distortion(TV)	Max.±1%
Max.Diameter*L (mm)	φ102x167
Materials	Glass+metal
